OBDSTAR ISCAN HONDA Marine Diagnostic Scanner & IMMO Programming Tool

Professional Marine Diagnostic Solution for HONDA Marine Engines

The OBDSTAR ISCAN HONDA Marine is a dedicated intelligent diagnostic tablet specifically developed for HONDA Marine engines and systems. Designed with professional marine technicians, service centers, and boat maintenance specialists in mind, this advanced diagnostic tool provides comprehensive system diagnostics, maintenance functions, and specialized service capabilities in a compact and portable device.

Powered by the RK3128 Quad-Core ARM Cortex-A7 processor and running on the stable Android 5.1.1 operating system, the ISCAN HONDA Marine delivers fast performance, accurate diagnostics, and an intuitive user experience through its responsive 5-inch capacitive touchscreen display.

Professional HONDA Marine Diagnostics

The ISCAN HONDA Marine provides comprehensive diagnostic coverage for HONDA marine systems, allowing technicians to quickly identify faults, monitor system performance, and perform essential maintenance operations.

Diagnostic Functions

• Read Diagnostic Trouble Codes (DTCs)

• Clear Fault Codes

• Live Data Stream Monitoring

• Active Tests and Component Activation

• ECU Configuration

• System Settings and Adaptations

• Coding Functions

• Vehicle Health Checks

• Sensor and Component Testing

Advanced Marine Service Features

The integrated OBDSTAR mobile application works alongside the diagnostic tablet to improve service efficiency and diagnostic accuracy.

Built-In Support Resources

• Diagnostic Socket Location Guide

• Flash Code Reference Database

• Technical Service Bulletins

• Maintenance Service Functions

• Service Lamp Reset Functions

• Basic System Parameter Information

These resources help technicians reduce troubleshooting time and improve repair accuracy.

Intelligent Data Analysis

Multiple data visualization modes allow users to analyze system performance in greater detail.

Data Display Modes

• Text Data Stream

• Waveform Graph Display

• Instrument Dashboard Display

These viewing options provide a clear understanding of engine performance, sensor operation, and system behavior.

Special Functions

The ISCAN HONDA Marine supports various advanced service operations, including:

• Device Configuration

• Maintenance Notification Settings

• Service Lamp Reset

• System Configuration Functions

• Real-Time Data Recording and Playback

Product Features

User-Friendly Operation

• Android 5.1.1 Operating System

• Simple and intuitive menu structure

• Easy navigation and operation

• Fast menu selection and workflow

Advanced Diagnostics

• Full system diagnostics

• Code reading and clearing

• Live data monitoring

• Active tests

• Coding and configuration functions

Connectivity & Updates

• Wi-Fi Connectivity

• One-Click Software Updates

• Remote Technical Assistance via OBDSTAR Support

• Automatic Software Upgrade Function

Extended Support

• 2 Years Free Software Updates

• Dedicated HONDA Marine Coverage

• English Language Support

Technical Specifications

System

• Operating System: Android 5.1.1

• Processor: RK3128 Quad-Core ARM Cortex-A7

Display

• Screen Size: 5.0 Inch

• Resolution: 800 × 480

• Touchscreen: Capacitive Touch Screen

Memory & Storage

• Supports up to 32GB Micro SD (TF) Card

Battery

• 2600mAh Rechargeable Polymer Lithium Battery

Connectivity

• Wi-Fi Supported

Environmental Specifications

• Working Temperature: -10°C to 55°C

• Storage Temperature: -20°C to 70°C

Physical Specifications

• Weight: Approximately 700g

• Dimensions: 198mm × 115mm × 31mm

Supported Applications

Designed specifically for:

• HONDA Marine Engines

• HONDA Outboard Diagnostic Systems

• HONDA Marine Electronic Systems

Package Contents

• 1 × OBDSTAR ISCAN HONDA Marine Diagnostic Tablet

• 1 × M001 Main Cable

• 1 × M015A HONDA Adapter Cable

• 1 × 12V 2A Charger

Why Choose OBDSTAR ISCAN HONDA Marine?

The OBDSTAR ISCAN HONDA Marine combines advanced diagnostic technology, intelligent troubleshooting support, and professional marine service functions into a single portable device. With live data analysis, ECU diagnostics, maintenance functions, and dedicated HONDA marine coverage, it provides an efficient and reliable solution for marine technicians and service professionals.

Its user-friendly interface, robust hardware, Wi-Fi connectivity, and two years of free software updates make it a valuable tool for maintaining and diagnosing HONDA marine systems with confidence.
