Autel MaxiBAS BT506 Car Battery Tester& Analyzer,Detection Rate of Bad Batteries

2 sold in last 8 hours
In stock
$349.99
Title *
$349.99
customers are viewing this product
Autel MaxiBAS BT506 Car Battery Tester& Analyzer,Detection Rate of Bad Batteries - Auto Lines Australia

PRODUCT HIGHLIGHTS

Autel MaxiBAS BT506 Car Battery Tester& Analyzer,Detection Rate of Bad Batteries

Autel MaxiBAS BT506 Car Battery Tester & Analyzer

Know Everything About Your Vehicle Battery and Charging System

Autel BT506 car battery tester

Autel MaxiBAS BT506 is a battery and electrical system analysis tool. It uses the advanced battery analysis method of adaptive conductance to check the cold start capacity and reserve capacity of the battery more accurately, which is very important to determine the true health of the battery. MaxiBAS BT506 battery tester enables technicians to view the health status of vehicle batteries and electrical systems. Download the free easy-to-use battery test mobile app for IOS and Android devices. Together with the BT506 battery analyzer , the application can complete battery, startup and charging system tests and display test results. The Autel BT506 can also be used with the latest autel advanced models (such as MS906s, MS906 Pro, MS906 Pro-TS, Ms Elite II tablet) as a supplement to battery testing and alternator testing.

Highlights of Autel BT506 Car Battery Tester

  • Support in-vehicle and out-of-vehicle testing
  • Test 6- and 12-volt batteries: 100 - 2000 CCA
  • Test 12- and 24- cranking/charging systems
  • Test Flooded, AGM, AGM Spiral, EFB and GEL batteries
  • Compatible with CCA, CA, SAE, EN, IEC, DIN, JIS and MCA
  • Creative Adaptive Conductance for 95% accuracy
  • Display test records in list form, offering a summary review tested and vehicles and/or batteries
  • PDF repair report for easy viewing, sharing, printing
  • Permanently valid FREE software updates
  • Purchase the Autel VCI V200P to upgrade the BT506 to the BT508 to get battery reset, battery change, and full system fault scan functions for one vehicle brand

Adaptive conductance technology, the diagnostic accuracy is more than 95%

Bt506 adopts adaptive conductivity technology

What is Adaptive Conductance?

Autel battery tester MaxiBAS family uses Adaptive Conductance [Valued 1000USD Technology] to gauge a battery’s conductance health. A low frequency alternating current is sent through the battery to determine its remaining plate area. This method’s advantage over ordinary load testers is its ability to allow multiple tests without draining the battery and to test batteries that are low or nearly completely discharged. This Autel car battery tool BT506 similarly uses Adaptive Conductance to test the battery’s partnering components, the alternator and starter to see if they can take and store a charge.

Put it in simple words, that will be:

  • Detect low-capacity batteries, 100% detection rate of bad batteries
  • Reduce Battery Misdiagnosis and retest
  • Diagnose Low Capacity or Completely Discharged Batteries
  • Reduce battery Misdiagnosis, Diagnosis accuracy rate over 95%
battery & starter & generator test

Autol MaxiBAS BT506, powerful beyond imagination

Universal battery test

Autel MaxiBAS BT506 digital battery load test tool supports in-vehicle and out-of vehicle testing of 6- and 12-volt, 100 -2000 CCA, Flooded, AGM, AGM Spiral, EFB and GEL batteries, and compatible with major battery test standards CCA, CA, SAE, EN, IEC, DIN, JIS and MCA. It can test almost all the transportation tools batteries such as car, boat, motorcycle or any other.

The battery test results include a color-coded results summary, a list of test data, and repair tips.

Starter test

Autel MaxiBAS BT506 can check the working condition of the vehicle starter, it helps you test and analyze the actual required starting current and starting voltage to check the if the starter works properly or not.

Generator test

With the Autel battery scan tool BT506, you can check and analyze the charging system status, thus to find out whether the output voltage of the generator is normal, whether the diode works properly or not, which helps avoid damaging the battery and shortening its life due to overcharging or incomplete charging.

User oriented simplest operation

User oriented simplest operation

On-screen instructions

New to the battery tester? No worries at all! Autel BT506 provides detailed and step to step instructions, just follow the on-screen indicators, you can finish battery diagnosis easily.

Automatically identify battery type

Clamp the BT506 to a in-vehicle battery, the vehicle information will be automatically populated and its battery information tab will pop up from the bottom of the screen, select the correct battery parameters on the screen to process the diagnosis.

Polarity protection

Metal clamps of the BT506 are protected by short-circuit protection, no worries even you reverse the positive and negative poles.

Easy repair report sharing

The Battery Test app can save a history of repair reports from your diagnostic sessions. Repair report in PDF can also be generated for the easy viewing, sharing, and printing of these reports.

More exploration, unlimited possibilities

More exploration, unlimited possibilities

Upgradeable to BT508

Want more functions? Purchase the Autel VCI V200P to upgrade the BT506 to the BT508 so it will be able to perform battery reset, battery change, and full system fault scan for one vehicle brand

Great addition to autel newest scanners

Already have an Autel scanner at your hands? Autel BT506will be a great addition for detailed vehicle battery health diagnostics. It is compatible with the newest models such as Autel Maxisys MS906 Pro, MS906 Pro-TS, MS Elite 2 to perform complete battery, cranking, charging systems check.

Lifetime free updates

Check regularly to see if there is latest firmware updates, you can download the free software updates valid for a lifetime to keep your BT506 scanner up to date.

Specifications

Item Description
Connectivity USB 2.0, Type C
Bluetooth   V3.0 BR/EDR+ V4.2 LE Dual-Mode
Input Voltage 5 V DC
Working Current < 150 mA at 12 V DC
Internal Battery N/A
CCA Range 100 to 2000 A
Voltage Range 6 to 36 V
Working Temperature -10°to 50° C (14° to 122° F)
Storage Temperature -20° to 60° C (-4° to 140° F)
Dimension (L x W x H) 107 mm (4.21“) x 75 mm (2.95”) x 26 mm (1.02”) (clamp   cable not included)
Weight 320 g (0.7 lb.)
