ANCEL PB600 12V 24V Car Circuit Power Probe Tester Relay Injector Battery Tool
ANCEL PB600 Car Circuit Probe Kit Circuit Tester Rleay Test 12V/24V Electrical Current Voltage Test Auto Battery Inspection Tools
Ancel PB600 Power Scan Kit is the most revolutionary circuit tester to date, working with 12-24 volt sources and providing DC voltage, AC voltage, Frequency, Duty Cycle, Injector Circuit, Resistor and Diode detection functions. Specifically in AC voltage, Frequency, Duty Cycle and Inject mode, the user can switch between waveform display mode and digital display mode by long pressing the mode button. The PowerScan is indeed the ultimate in performance and affordability, allowing the user to check circuits in a single step. An absolute must for any technician looking for a fast and accurate solution for diagnosing electrical systems.
ANCEL PB600 Automotive Circuit Tester – All-in-One Multimeter, Oscilloscope, Injector & Relay Tester for 12V/24V Vehicles
The ANCEL PB600 is a next-generation automotive circuit tester and diagnostic probe that combines the power of a multimeter, oscilloscope, injector tester, relay tester, and more—into one compact, easy-to-use tool. Whether you're a professional mechanic or a DIY auto enthusiast, the PB600 provides all the essential diagnostic functions you need to test, diagnose, and repair complex vehicle electrical systems efficiently and safely.
ANCEL PB600 Electrical System Circuit Tester Functions:
✔️ Diagnose 12 ~24V automotive electrical systems swiftly and accurately.
✔️ Show battery voltage reading and help user determine circuit polarity immediately after connecting the KM50 clips to the vehicle battery.
✔️ Test DC Voltage, AC Voltage, Frequency, Duty Cycle, Fuel Injection Circuit, Resistance, and Diode. Especially, in AC Voltage, Frequency, Duty Cycle and Fuel Inject Modes, user can long press the mode button for 3 seconds to switch between Waveform Display Mode and Digital Display Mode.
✔️ Activate electrical components and test their functions without jumper leads – by depressing the rocker switch to conduct a positive or negative battery current to the tip so as to power up electrical components.
✔️ Test bad ground contacts instantly without performing voltage drop tests.
✔️ Help user to follow and locate short circuits without using external fuses.
✔️ Test continuity with the assistance of its auxiliary ground lead.
✔️ The tool is short-circuit protected. If it becomes overloaded, Its internal circuit breaker will trip to protect the instrument from overload.
✔️ When the circuit breaker is tripped, the tool will NOT be able to conduct battery current to the tip even when the rocker switch is pressed; however, all other functions of the tool are still active, which means you can still probe a circuit and observe the voltage reading.
Multiple Functional Modules in One Powerful Device
The PB600 offers extensive functionality that rivals—and even surpasses—many individual diagnostic tools on the market today. It includes:
-
Multimeter functions (Voltage, Resistance, Diode, Frequency)
-
Oscilloscope mode with waveform display
-
Continuity test with buzzer
-
Relay test function for 4/5-pin relays
-
Component activation directly from the probe
-
Power/ground/open & short circuit detection
-
Trailer light testing
-
Fuel injector testing and cleaning
-
PN-junction and diode analysis
-
20-foot extension cable for maximum mobility
-
Bright built-in LED light for dark engine bays
-
AC/DC voltage test range of -110V to +110V
-
Data display on a 2.4” HD TFT screen
PB600 - Upgrade of PB500
PB600 has Fuel Injector Testing, Frequency Testing, Duty Cycle Testing, and Display Forms: Waveform. These are the features that PB100 does not have.
Multimeter & Oscilloscope Test Module
The PB600 acts as a fully functional multimeter with advanced oscilloscope capabilities. Measure:
-
DC/AC Voltage
-
Resistance (0~1MΩ)
-
Diode forward voltage
-
Current (AMP)
-
Frequency (0Hz–1MHz)
-
Duty Cycle (0–100%)
Its oscilloscope mode offers a waveform view of AC voltage, frequency, and duty cycle, helping diagnose issues related to sensors, actuators, and signal integrity in real time. All data is displayed on a 2.4-inch HD LCD screen (320×240 DPI) with intuitive layout and clear visual indicators.
ANCEL PB600 has 8 test modes:
Especially, in AC Voltage, Frequency, Duty Cycle and Fuel Inject Modes, user can long press the mode button to switch between Waveform Display Mode and Digital Display Mode.
Instant Component Activation & Electrical Testing
The PB600 lets you apply power or ground directly to components using the probe tip. This makes it ideal for:
-
Activating lights, motors, fans, relays, injectors, and solenoids
-
Testing bad grounds, open/short circuits, and voltage drops without the need to dismantle wiring
-
Dynamic component testing without separate wiring or tools
2 Forms Display Mode
To switch Waveform Display Mode and Digital Display Mode. (In AC Voltage, Frequency, Duty Cycle and Fuel Inject Modes)
99% Vehicels Support:
Fuel Injector Testing & Cleaning Function
Fuel injector maintenance is critical for modern engines. The PB600 can generate four pulse modes to test and clean injectors when combined with a standard fuel injector cleaner. This function allows you to:
-
Trigger injectors manually or automatically
-
Measure injection voltage (0–180V) and pulse time (0–25ms)
-
Switch between waveform and digital display modes for precision
Relay Testing Simplified
Avoid unexpected breakdowns caused by faulty relays. The PB600 includes a dedicated relay test module that works with standard 4-pin and 5-pin automotive relays, allowing you to verify relay operation with:
-
Relay test wires and auxiliary probes
-
Clear pass/fail indicators
-
On-the-spot component verification for headlights, fans, radios, and more
🔌 Smart Auto-Detection with Real-Time Feedback
Equipped with smart test functions, the PB600 automatically detects and displays:
-
Positive/negative polarity
-
Voltage/resistance levels
-
Continuity with audible buzzer
-
Waveforms for complex signals
No manual range selection is needed—just probe and go. The 20-foot cable lets you access hard-to-reach areas from the driver seat or rear of the vehicle with ease.
🔋 Comprehensive Battery Testing Module
The PB600 includes a complete 12V battery test suite for:
-
Battery Health Test
-
Cranking Test
-
Charging Test
With a rating range of 100–2000 CCA, it supports most vehicle batteries and helps you diagnose performance issues before they lead to failure.
🌐 Technical Specifications
| Feature | Specification |
|---|---|
| Display | 2.4" TFT LCD (320×240) |
| Supply Voltage | DC 8V–35V |
| AC/DC Voltage Test | ±110V (True RMS) |
| Resistance | 0–1MΩ |
| Frequency | 0Hz–1MHz |
| Duty Cycle | 0–100% |
| Fuel Injection Pulse | Voltage: 0–180V, Time: 0–25ms |
| Battery Test Range | 100–2000 CCA |
| Operating Temp | -20°C to 50°C (-4°F to 122°F) |
| Storage Temp | -40°C to 65°C (-40°F to 149°F) |
| Dimensions | 228 × 80 × 32mm |
| Rating Current | 1A–8A |
Double Overload Protection
Safety is a top priority with the PB600. It includes:
-
Internal circuit breaker
-
External 10A fuse on the ground line
This dual protection system prevents damage to the device and your vehicle in the event of a short circuit or overload. The kit also includes 2 extra fuses for quick replacement.
Built-in Utility Features & Accessories
-
LED work light for low-light environments
-
Sharp test probe & crochet hook for no-removal testing
-
30ft total cable length for extended reach
-
Includes: probes, piercing needles, hooks, relay test cables, fuses
-
Multilingual support, polarity indicators, and buzzer alerts
-
Free firmware updates and version upgrades via USB
-
Appearance design protected by patent
Important Usage Tips
-
Only use the PB600 on 12V/24V vehicle systems; not for 110V/220V household use.
-
Safe for sensitive vehicle electronics like airbags and ECUs—draws <100mA when measuring.
-
To protect the rocker switch when powering components, press the switch before making contact with the tip.
-
AC voltage mode supports True RMS readings for accurate signal analysis.
What Can You Do With the PB600?
-
Diagnose vehicle electrical issues
-
Trace and follow short circuits
-
Perform relay and fuse tests
-
Test and clean fuel injectors
-
Activate electrical components
-
View signal waveforms
-
Monitor battery status
-
Identify broken wires, poor grounds, and more
Complete Package Includes
-
ANCEL PB600 Main Unit
-
20ft extension cable
-
Relay test wires and connectors
-
Needle probes and hooks
-
Piercing probes
-
Spare 10A fuses (2 pcs)
-
User Manual
-
Carrying Storage Box
